Common mode choke core with nanocrystalline material for EMC solution

Current Transformer cores and switches have either strong or Split Cores and in addition transfer yields, LED affirmation, and a customizable set point. Current transformer permits easy monitoring of the current flowing to your load. Accessible in number of various reaches. Current transformer is a minimal effort elective for measuring power and checking the operation of fans, pumps or other equipment.
Compared to silicon steel core the Nanocrystalline show following benefits:

Initial Permeability : Nanocrystalline Core is 7 times more than Silicon Steel Core .

Our Nanocrystalline CT Core can meet ANSI 0.05-0.1 class,because Nanocrystalline permeability is high up to 150,000.

No-Load Loss: Nanocrystalline Core is 1/5 less than Silicon Steel Core .

Higher precision, Smaller volume and weight: Nanocrystalline Core is 1.28 less than Silicon Steel Core (Weight)

Application:

High-power switching power supply and inverter welding inverter power transformer

UPS uninterruptible power supply

Communications equipment

High frequency induction

Heating power supply

Charging power supply
